QUAWE tricycle refrigerated boxes is a specialized cooling solution that combines a three-wheeled vehicle (tricycle) with an integrated refrigerated boxes. Cold storage boxes are versatile, standalone units, designed specifically for small-scale cold storage and mobile applications. These units feature insulated with high-quality polyurethane panels, ensuring excellent thermal retention and energy efficiency.This innovative transportation system is designed to maintain consistent low temperatures, making it ideal for delivering temperature-sensitive goods such as food, beverages, and medical supplies.
Specifications of Refrigerated Box
●The sheet is made of polyurethane and stainless steel.
●Panels thickness is 75 mm, insulated box and refrigerated box. Providing good insulation.
●Panels made of polyurethane foam and stainless steel are used for walls, ceilings, floors and door.
●The density of PU panels is 42±2 kg/m3.
●PU panels can reach fireproof level B2.
| Product name | Tricycle Mobile Cold Room Refrigerated Box |
| Refrigerant | R404A |
| Panel thickness | Polyurethane 75mm or customized |
| Voltage | Battery 48V45Ah |
| Cold storage size | 1500*1000*1000/1600*1100*1100/1800*1200*1200/2000*1200*1200 or customized |
| Cold room doors | 1pcs/customized |
| Material | Colored Steel+Stainless Steel Floor |
| Temperature of freezer | +5~-18℃ |
| Application Scenarios | Cold Chain Delivery For FruitsCold Chain Distribution For Catering StoresSeafood Cold Chain Distribution |
Main Features of Container Cold Room
Tri-wheel motor tricycle Refrigerated box with All – Closed FRP / GRP insulated Sandwich Panel Kits and refrigerator units
Refrigerated truck, sometimes we call it reefer Refrigerated box body. Sometimes we callit freezer truck box body. Sometimes chiler truck box body. Sometimes cold room truck box body. All in all. We calls it refnigerated truck.Reefer truck box body is a kind of box which can loacthe cargoes which need to keep cold and fresh. Such as icecream. chill chicken, chill fish. freezer meat, sometimes vegetables and so on.
The palts of FRP reefer truck box body is adopted the hiohest confiquration. They are 304 stainless steel parts for door lock and doorirame. Aluminum profile for connecting all the panels. The importing rubbers make the door be sealing. So the whole reefer truck boxbody is all-closed without any gap.
