Ice Brick Block Make Machine Description

Ice brick block machine is a heavy-duty system designed to produce large, solid blocks of ice (5kg to 150kg). Its key advantage is producing ice that melts very slowly, making it ideal for long-term cooling. These fully automated machines are built for durability and high capacity, serving critical roles in the fishing, construction, Ocean Zoo,chemical, and food processing industries where large-volume, sustained cooling is essential.Featuring an integrated design, the industrial ice block machine is easy to install—simply connect the power supply and water pipe to start using it. Both the size and production capacity of the block ice can be customized according to customer requirements.

Features of ice brick block machine

1. The sheet metal structure is reasonable, the strength is high, and it is not easy to deform.

2. Excellent structural design, shorter freezing time.

3. Adopt welding or riveting method to improve the service life.

4. Stainless steel sheet and hot-dip galvanized steel sheet are optional.

5. There are many types of ice molds: 5KG, 10KG, 15KG, 20KG, 25KG, 30KG, 50KG, 100KG, 125KG, 135KG and other specifications.

6.Microcomputer temperature control system: precise temperature control, easy to operate

7.Big-brand compressor system: accelerated cycle, efficient refrigeration;

8. The specifications are diversified and can be customized according to customer requirements

Model	QW-0.5	QW-1	QW-1	QW-2/3/5
Daily output	500KG	1ton	1ton	2ton/3ton/5ton
Voltage	220/380V	380V 50HZ	380V 50HZ	380V 50HZ
Power	3.5KW	6KW	6KW	9.5KW/12KW/20KW
Compressor	Meizhi 3P	Panasonic 6P	Panasonic 6P	Panasonic 10P/11P
Refrigerant	R22/R410	R22/R410	R22/R410	R22/R410
Mold size and ice mold weight	150*70*600MM 5KG	262*77*620MM 10 KG	150*70*600MM 5 KG	262*77*620MM 10KG
Mold quantity	16 pieces	18 pieces	35pieces	35 pieces
Ice time	once every 4 hours	once every 4 hours	4 hours/batch	once every 4 hours
Net weight	245KG	300KG	383kg	540KG/500KG/800KG
Machine size	1565*1060*1010+260MM	2595*890*1020+260MM	2595*890*1020+260MM	2965*1295*1015+285MM

Product Processing Effect
