Industrial Ice Machines

An industrial ice machine is a high-capacity refrigeration system engineered to produce large volumes of ice continuously for commercial, industrial, and institutional applications. Unlike residential ice makers, these robust systems are built for durability, efficiency, and reliability in demanding environments.An industrial ice machine is a specialized equipment designed for the large-scale production of ice. The ice production capacity ranges from 1T/day to 30T/day,which can meet the needs of industrialand commercial ice.

· Flake Ice: Soft, malleable, and dry. Perfect for food processing (mixing, grinding), fisheries (packing and displaying fish), concrete cooling, and chemical plants.

· Cube Ice (or Full Cube): Hard, slow-melting, and clear. Ideal for beverage service (hotels, restaurants), healthcare (patient cooling), and food display.

· Nugget Ice: Chewable, compact, and absorbs flavors quickly. Highly popular in healthcare (hospital patient trays), fast-food chains (soft drinks), and bar service.

· Tube Ice: Cylindrical, hollow, and very hard. Commonly used in seafood preservation, dairy processing, and chemical industries.

· Food & Beverage: Food processing, preservation, bakeries, beverage production, and dairy plants.

· Hospitality & Retail: Hotels, restaurants, bars, supermarkets, and convenience stores.

· Healthcare & Science: Hospitals, laboratories, and research facilities for medical and scientific cooling.

· Fishing & Aquaculture: Onboard fishing vessels and at aquaculture farms for preserving the catch.

· Construction & Concrete: Pouring temperature control for large concrete structures.

· Chemical & Industrial Processes: As a cooling medium in various chemical reactions and manufacturing processes.

ModelOutputInput PowerCooling capacityWeightUnit sizeCondenser Size
QW-11t/24h6.21KW11.9KW950KG1440*900*1950mm1100*450*870mm
QW-22t/24h8.39KW18.8KW1150KG1650*1300*2150mm1100*500*870mm
QW-33t/24h14.5KW33.5KW1280KG1650*1300*2150mm2000*650*1145mm
QW-55t/24h23.8KW50.7KW1600KG1750*1400*2200mm2000*700*1145mm
QW-1010t/24h42.8KW80.9KW2750KG2300*1600*3100mmφ1385*2150mm
QW-2020/24h82KW161.9KW5200KG2400*2100*2250mmφ2900*2690mm
QW-3030t/24h115KW242.7KW6400KG2900*2100*2250mMφ2900*2875mm
